+Touch screen operation system, control simple and straight
+Memory store function, makes data resue be possible
+Auto positioning increase adjusting speed
Max. Center Distance Between Holes:L*B=2450mm*672mm
Min. Center Distance Between Holes:L*B=250mm*32mm
Plate Thickness:8-50mm
Total Number Of Spindles: 132pcs
Spindle Speed:2840rpm
Vertical Drill Moving Speed:5-36m/min
Qty. Of Vertical Drilling Rows:4 rows
Air Pressure:0.5-0.6mpa
Motor Voltage:380V, 60Hz, 3Phase
Horizontal Drill Moving Speed:5-36m/min
Processing Speed:13-16pcs/min
+Can perform four faces holes drilling at a time
+Chain Feeding, can process two boards at a time
+Touch screen plus PLC control, easy for operation
Max. Center Distance Between Holes:L*B=1500mm*672mm
Min. Center Distance Between Holes:L*B=220mm*32mm
Plate Thickness:8-50mm
Total Number Of Spindles: 96pcs
Spindle Speed:2840rpm
Total Power:12.6kw
Net weight: about 1100kg
Overall Dimensions:3400*2250*2200mm
Single Plate Processing Speed:13-16pcs/min
Single Plate Processing Width:60-630mm
Double Plates Processing Width:60-280mm
Double Plates Processing Speed:20-26pcs/min
+Can perform four faces holes drilling at a time
+Chain Feeding, can process two boards at a time
+Touch screen plus PLC control, easy for operation
Max. Processing Length：2450mm
Max.Drilling Dia.：35mm(single bit)
Max.Drilling Depth：50mm
Installation Dia. Of Drill Bit Shaft：10mm
Knife Installation Length：57mm/70mm
Spindle Speed：2840rpm
Air Pressure：0.5-0.6mpa
Motor Voltage：380V,50Hz
Total Power：4.4 kw
Net Weight：about 550kg
Overall Dimensions：2700×800×1550mm
